What's happening in the field?
At the Missouri State Fruit Experiment Station

Improving internal water drainage in high tunnel

The east end of the high tunnel tends to collect water. Randy and Jeremy decided to install a tile drainage system to solve this problem. The system was installed today.

Trenches were dug about 18 inches deep in the poorly drained area.
Trenches were dug about 18 inches deep in the poorly drained area.
After the trenches were dug, perforated pipe was put in them. The end of the pipe was covered with screen.
After the trenches were dug, perforated pipe was put in them. The end of the pipe was covered with screen.
The perforated pipe was checked with a level so that it sloped to the east.
The perforated pipe was checked with a level so that it sloped to the east.
Gravel was added to any low areas so the water would flow to the end of the tunnel.
Gravel was added to any low areas so the water would flow to the end of the tunnel.
Pipe connected the two ends of the perforated pile and this ran outside to divert the water.
Pipe connected the two ends of the perforated pile and this ran outside to divert the water.
Here is the assembly at the low end of the tunnel with the pipe running outside.
Here is the assembly at the low end of the tunnel with the pipe running outside.
The perforated pipe is covered with some gravel and then they will be covered with soil.
The perforated pipe is covered with some gravel and then they will be covered with soil.
Posted in High Tunnel | Leave a comment

Setting up overhead irrigation in the high tunnel

We are getting ready to plant larkspur seed and lettuce transplants in the high tunnel. We are going to plant one bed in the middle of the space to observe how vegetable harvest coincides with the raspberries that were planted in bags last year being moved back into the tunnel for production. Randy, Jeremy and Amanda are setting up the overhead irrigation sprinklers that hang from a wire overhead. The larkspur seed was planted and watered in after the 13-13-13 fertilizer was tilled in at the rate of 1 pound per 100 square feet.

Randy )left), Amanda and Jeremy install the hanging sprinklers to a hose suspended overhead.
Randy )left), Amanda and Jeremy install the hanging sprinklers to a hose suspended overhead. The sprinklers are spaced 3 feet apart down the hose.



First the sprinkler head is attached to the spaghetti  tube.
First the sprinkler head is attached to the spaghetti tube.
Here is the assembled sprinkler.
Here is the assembled sprinkler.
Jeremy punches a hole in the suspended hose.
Jeremy punches a hole in the suspended hose.
The sprinkler is inserted into the hose using the weight to help push it in.
The sprinkler is inserted into the hose using the weight to help push it in.
The sprinklers are spaced 3 feet apart and the weight holds them down. The sprinklers more than cover the intended area.
The weight holds them down and in place. The sprinklers covered the intended area more than adequately.
Posted in High Tunnel | Leave a comment

Grape pruning of the winter hardy cultivars

We are pruning the winter hardy cultivars of grapes first and will prune the less hardy cultivars later in the winter. Dr. Anson Elliott decided to check on the pruning progress on this bright and sunny day. Randy, Aaron, Manny and Kellis were pruning the Norton block in the Research Vineyard while Shelia and Jeremy were taking wood weights in the Catawba block. After the Norton block is complete, they will move into the Catawbas.

The pruning crew is working on the Norton vines in the Research Vineyard.
The pruning crew is working on the Norton vines in the Research Vineyard.
Manny shows Dr. Elliott how he selects spurs that originate close to the cordon.
Manny shows Dr. Elliott how he selects spurs that originate close to the cordon.
Shelia and Jeremy are taking the wood weights in the Catawba block. The wood weights help determine the number of buds to leave on the vines.
Shelia and Jeremy are taking the wood weights in the Catawba block. The wood weights help determine the number of buds to leave on the vines.
Posted in Grapes | Leave a comment

Happy retirement to Pam

Pam Mayer is retiring from the State Fruit Experiment Station after 28 years of service. Many nice things were said, the common thread being how we will all miss her work, her work ethic and her willingness to help. We are all wondering how we will be able to manage without her!

Happy retirement thoughts!
Happy retirement thoughts! Photo by Alicia Mosier.
Dr. Elliott expresses appreciation for Pam's excellent work at the State Fruit Experiment Station.
Dr. Elliott expresses appreciation for Pam’s excellent work at the State Fruit Experiment Station. Photo by Alicia Mosier.
Dr. Hwang livens things up!
Dr. Hwang livens things up! Photo by Alicia Mosier.
We will all miss Pam, but wish her the best in her retirement years.
We will all miss Pam, but wish her the best in her retirement years. Photo by Alicia Mosier.
Dr. Elliott and Pam Mayer stand together for a photo in the Paul Evans Library of Fruit Science.
Dr. Elliott and Pam Mayer stand together for a photo in the Paul Evans Library of Fruit Science.
Posted in Events | Comments Off

Holiday Party at the MSU Fruit Experiment Station

We had our delicious holiday lunch today in Faurot Hall. Folks from main campus, Journagan Ranch and the Fruit Experiment Station exchanged dirty Santa gifts and enjoyed the feast.

Our annual group photo.
Our annual group photo.
Dr. Elliott gives a fireside chat.
Dr. Elliott gives a fireside chat.
Chin Feng, Karl and C.J. compete in the annual tacky tie contest.
Chin Feng, Karl and C.J. compete in the annual tacky tie contest.
Wenping won two purses in the dirty Santa gift giving (and stealing).
Wenping won two purses in the dirty Santa gift giving (and stealing).
Here is the back corner bunch.
Here is the back corner bunch.
Fruit stationers.
Our Fruit Station folks.
More fruit stationers.
And more Fruit Station folks.
The Darr group.
Our main campus group.
C.J. and Mike.
C.J. and Mike.
Dessert time.
Dessert time.
The laboratory lads and lasses.
The laboratory lads and lasses (and Clayton).
Steven and Pam.
Steven and Pam.
Sally and Pam.
Sally and Pam.
Shelia and Amanda (otherwise known as the "A" team.)
Shelia and Amanda (otherwise known as the “A” team.)
Posted in Events | Comments Off

Putting the raspberries to bed for winter

Yesterday we collected pruning weight data on the “High Tunnel Production Rotation of Primocane Bearing Raspberries in Grow Bags” project funded through the USDA Specialty Crops Block Grant Program. Today we moved the raspberries out of the high tunnel to the field and then protected them from winter cold with straw mulch.

Here are the raspberries in grow bags after the canes have been cut down.
Here are the raspberries in grow bags after the canes have been cut down.
The bags are pulled out of the rows.
The bags are pulled out of the rows. The bags are marked with cow ear tags color coded to experimental block. The tag also is marked with location in the row and cultivar identity.
The raspberry roots grew out of the bottom of sides of the grow bag. This did not damage the grow bag.
Kellis holds us a grow bag to show that the roots grew out the bottom on the sides. This did not damage the grow bag.
Roots even grew from bag to bag where the bags were touching each other.
Roots even grew from bag to bag where the bags were touching each other.
Manny leads the train moving the bags from the tunnel to the field.
Manny leads the train moving the bags from the tunnel to the field.
Straw bales are placed around the bags for winter protection.
Straw bales are placed around the bags for winter protection.
About 4 to 6 inches of straw is fluffed up and put over the top of the grow bags.
About 4 to 6 inches of straw is fluffed up and put over the top of the grow bags.
We finished this task quickly with all of our crew. (Left) Kellis, Jeremy, Shelia, Manny, Amanda, Aaron and Randy.
We finished this task quickly with all of our crew. (Left) Kellis, Jeremy, Shelia, Manny, Amanda, Aaron and Randy.
Posted in Alternative crops, High Tunnel | Comments Off

Taking dormant season data for raspberry project

Today we are collecting dormant season data from the “High Tunnel Production Rotation of Primocane Bearing Raspberries in Grow Bags” project funded through the USDA Specialty Crops Block Grant Program. We needed to strip leaves since they did not fall yet. The number of bearing canes and the pruning weight per replication were collected.

First the catch twine was removed from the trellis.
Shelia Long (left) and Amanda Gonzales first remove the catch twine from the trellis.
Then the leaves were stripped since they didn't fall on their own.
Then the leaves were stripped since they didn’t fall on their own.
The canes that bore fruit were counted.
The canes that bore fruit were counted.
Canes were cut out from the grow bags after they were counted.
Canes were then cut out from the grow bags.
The cut canes from each replication were weighed and the weights were recorded.
The cut canes from each replication were weighed and the weights were recorded.
Posted in Alternative crops, High Tunnel | Comments Off

A marcescent fall is when the leaves don’t drop

We are waiting (and waiting) for the apple leaves to fall in order to begin pruning – but it just isn’t happening. If deciduous trees don’t drop their leaves as they should, we say we have a marcescent falll. Marcescent means the trees hold their leaves into winter. It is often triggered by a sudden change from warm to cold temperatures during the fall. Trees prepare for winter by absorbing nutrients from the leaves to store over winter. At the same time they to form an abscission layer at the base of the petiole or leaf stalk to enable the leaf to break away from the tree after the nutrients have been absorbed. If warm weather changes quickly to cold, it can kill green leaves before the abscission layer has formed and the leaves are “stuck” on the tree. They will eventually become unstuck, but this will take considerably more time.

These apple trees have not dropped their leaves yet as they were not able to produce an abscission layer at the base of the petiole.
These apple trees have not dropped their leaves yet as they were not able to produce an abscission layer at the base of the petiole.
You can see these leaves were green when they froze and died without dropping.
You can see these leaves were green when they froze and died without dropping.
Posted in Apples, Weather | Comments Off

Symptom on Polka primocane bearing raspberry

We finished harvesting the primocane bearing raspberries in grow bags on October 31 for the trial funded by the USDA Specialty Crop Block Grant Program. We noted symptoms of a disorder on the Polka variety, but not on the other varieties in the trial (Josephine, Crimson Giant, Himbo Top, and Joan J.)

Dr. Courtney Weber, Associate Professor and Small Fruits Breeder at Cornell University – NYSAES was consulted about this problem and he mentioned that he had seen this before and it was fairly typical on the Polka variety later in the season. It may possibly be the natural senescence pattern of Polka leaves and does not seem to affect the long term performance of the plantings.

Leaf curl and discoloration of Polka raspberry at the end of the growing season October 30, 2014.
Leaf curl and discoloration of Polka raspberry at the end of the growing season October 30, 2014.
Top side of affected Polka leaf.
Top side of affected Polka leaf.
Underside of affected Polka leaf.
Underside of affected Polka leaf.



Posted in High Tunnel | Comments Off
